Multi-functional Combined Hydraulic Copper Busbar Cutting Punching Bending Machine
This device is a portable modular hydraulic busbar processing machine with three working units for bending, cutting, and stamping functions. Features: Punching without burrs, smooth cutting surface, accurate bending angle. The foot switch is safe and firm, and can control the oil inlet and outlet. The product model is DSMX-70, with a busbar cutting capacity of 200mmx12mm. The busbar cutting machine has a production capacity of 35T, a throat depth of 110mm, and a weight of 230kg
Description
Product Description
Multi-functional Combined Hydraulic copper Busbar Cutting Punching Bending Machine
This busbar processing machine is used for on-site workshop operations and electrical
equipment manufacturing, such as distribution cabinets and switchgear. This machine
has functions such as cutting, punching, and bending.
|
Model |
DSMX-70 |
|
Functions |
Cut/ Punch /Bend |
|
voltage |
220V/380V |
|
oil pressure |
700kgf/cm² |
|
Output of cutting machine |
35T |
|
Bus bar cuttting capability |
200mm×12mm |
|
Output of bus bar cutter |
35T |
|
Depth of throat |
110mm |
|
Standard setting |
Ø 7, Ø 9, Ø 10.5, Ø 13.8, Ø 17.5, Ø 20.5mm |
|
Punching capacity |
Ø 6 - Ø 20.5mm |
|
Output of bending machine |
15T |
|
Bending capacity |
200mm x12mm |
|
Weight |
230kg |
|
Size |
840 x900 x1200mm |
Product Details
1.Independent workbench
The functions of punching, cutting, and bending are integrated, and laser limiters can be installed.
It is suitable for busbar processing machines and does not interfere with each other, greatly improving
work efficiency.
2.Reversing Valve
Simply rotate the steering valve to easily switch, with simple operation and high work efficiency.
3.Pressure gauge
Clear instrument indications effectively prevent the impact of vibration.
4.Built in solenoid valve
Adopting all copper motors, high work efficiency and stable operation.
5.Swivel casters
360 degrees displacement casters are convenient for moving and can also be locked and fixed.
Multi-functional Combined Hydraulic copper Busbar Cutting Punching Bending Machine
Jinan Deshang CNC Equipment Co., Ltd. is a professional manufacturer of busbar processing machines,
copper and aluminum row processing machines, and busway processing equipment. It has 15 years of
production experience, mature technology, high output, fast delivery, and guaranteed after-sales service .
Our products have ISO9001 and CE quality certificates and SGS certification to escort customers' orders.
At the same time, DESG also accepts OEM or ODM orders, the minimum order quantity is one set. DESG's
product categories include: three-in-one busbar processing machine, mobile busbar processing machine,
busbar tools and other types of equipment, making it easier for users to choose the most suitable machine
for their work, so our equipment can meet customers' requirements for manufacturing aluminum and All
application scenarios of copper busbars are required. Machining accuracy is the most important characteristic
of equipment, and DESG machines are very precise in cutting, punching and especially bending, which is exactly
the element of precision that users of this type of machine are looking for.
Multi-functional Combined Hydraulic copper Busbar Cutting Punching Bending Machine
FAQ
1.What is your payment terms?
40% T/T deposit, 60% balance be paid before loading after good ready.
2. What is your delivery time?
Within 5working days after your deposit.
3. What is your power supply?
We could customized it according to your countries power supply.
4. What is your Min order quantity?
One set.
5. Are all the labels and instuctions of the machine in English?
Yes. The labels on the machine and the manual books are Write in English .
6. What other busbar processing related machines do we provide?
We provide you with multiple options: Busbar winding machine, busbar chamfering machine, copper
plate leveling machine, portable busbar processing machine,busbar cutting tools, busbar bending tools,
busbar punching tools,hydraulic pump, hand pump, etc.
