Cnc Turret Bus Processing Machine 303esk Copper Aluminum Busbar Machine

Busbar Machine Model		DSMX-303ESK-B
Punching	Max.Puncing Force (KN)	300
	Punching Diameter Range (MM)	Ø4.3-Ø30
	Max. Thickness (MM)	12
	Max. Width (MM)	160
Shearing/ Cutting	Max.Shearing Thickness(KN)	12
	Max. Shearing Width (MM)	160
	Max. Bending Force (KN)	500
Vertical Bending	Max. Thickness (MM)	10
	Max. Width (MM)	100
Horizontal Bending	Max. Width (MM)	12
	Max. Width (MM)	150
Twisting Bending	Max. Thickness (MM)	12
	Max. Width (MM)	160
Out Dimension	Out Dimension	1890*1350*1400
Power	Power	3 x 4kw
CNC Precision	Bending Precision	±1°
	Repeat Bending Precision	±0.3°

Cnc Turret Bus Processing Machine 303esk Copper Aluminum Busbar Machine

Punching unit
The turret punching structure is wear-resistantand efficient, and thefour-hole, six-hole and eight-hole turret mold nesting system madeof ductile cast iron has a long service life, high accuracy and easy relacement.

shearing unit
The shearing station adopts double column shear structure ,force is larger , theshear is flat and

there is no waste , and it is not easy to appear burrs ,collapsed feet and other phenomena.

Bending unit

Adopting closed bending, the output point and force point are on the beam, therefore

The mechanical strength is greatly enhanced to ensure the consistency of the processed workpiece

Up and down angles.

Adopting CNC Siemens PLC system

1. Touch colored screen ,General bending parameters can be saved

2. Only need to input the thickness and width of copper busbar, busbar machine will run automaticlly

3. Saving data, power off memory

4. Multilanguage system: Busbar Machine supports English, Spanish, Portuguese, Russian, etc.



Product Samples

Product Application

Mainly used for processing various types of copper and aluminum bars such as high and low voltage

switchgear, substations, transformers, electrical switches, chassis cabinets, large bus ducts, etc.

Company Profile

Jinan Deshang CNC Equipment Co., Ltd. is a professional manufacturer of busbar processing machines, copper and aluminum row processing machines, and busway processing equipment. It has 15 years of production experience,

mature technology, high output, fast delivery, and guaranteed after-sales service .
Our products have ISO9001 and CE quality certificates and SGS certification to escort customers' orders. At the

same time, DESG also accepts OEM or ODM orders, the minimum order quantity is one set.



Company Certificate

Factory

The company currently has 92 employees, including 23 professional and technical personnel with intermediate

and senior technical qualifications. Those with a college degree or above account for 54% of the company's

employees. The company integrates research and development, production, sales, and service, relying on

advanced technology and closely following the world trend of industrial intelligence development.

Main Markets

Busbar processing machinery manufacturers serve the world

Product packaging

Standard import and export wooden box packaging, free from fumigation and rust prevention treatment.
